- Cooling system: NEIN
- Usage Scenario: Gaming
- PCIe VERSION: PCIe 5.0 x 16
- Support Memory Channels: 2
- Support Memory Type: DDR5
- Support Chipset Models: Intel B85
- Default TDP / TDP: 125W
- Number OF Therads: 20
- Unlocked: NEIN
- GPU-built: Ja
- Chip Process: 10 NM
- Package: NEIN
- Processor Type: Intel core i5
- Typ: Fourteen-Core
- Socket Type: FCLGA1200
- Anwendung: Desktop
- Markenname: Intel
- Intel Model: 14600KF
- Herkunft: Festlandchina
- Number of Cores: Fourteen Cores
- Modellnummer: Intel i5-14600KF
Essentials
Product Collection
Intel Core i5 Processors (14th gen)
Code Name
Products formerly Raptor Lake
Vertical Segment
Desktop
Processor NumberÂ
i5-14600KF
LithographyÂ
Intel 7
Recommended Customer PriceÂ
$294.00-$304.00
CPU Specifications
Total CoresÂ
14
# of Performance-cores
6
# of Efficient-cores
8
Total ThreadsÂ
20
Max Turbo FrequencyÂ
5.3 GHz
Performance-core Max Turbo FrequencyÂ
5.3 GHz
Efficient-core Max Turbo FrequencyÂ
4 GHz
Performance-core Base FrequencyÂ
3.5 GHz
Efficient-core Base FrequencyÂ
2.6 GHz
CacheÂ
24 MB Intel® Smart Cache
Total L2 Cache
20 MB
Processor Base PowerÂ
125 W
Maximum Turbo PowerÂ
181 W
Supplemental Information
Marketing Status
Launched
Launch DateÂ
Q4’23
Embedded Options AvailableÂ
NEIN
Use ConditionsÂ
PC/Client/Tablet
Datasheet
View now
Memory Specifications
Max Memory Size (dependent on memory type)Â
192 GB
Memory TypesÂ
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Up to DDR4 3200 MT/s
Max # of Memory ChannelsÂ
2
Max Memory BandwidthÂ
89.6 GB/s
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express RevisionÂ
5.0 and 4.0
PCI Express Configurations ‡Â
Up to 1×16+4, 2×8+4
Max # of PCI Express LanesÂ
20
Package Specifications
Sockets SupportedÂ
FCLGA1700
Max CPU Configuration
1
Thermal Solution SpecificationÂ
PCG 2020A
TJUNCTIONÂ
100°C
Package Size
45.0 mm x 37.5 mm
Max Operating TemperatureÂ
100 °C
Advanced Technologies
Intel Gaussian & Neural AcceleratorÂ
3.0
Intel Thread DirectorÂ
Ja
Intel Deep Learning Boost (Intel® DL Boost) on CPUÂ
Ja
Intel Speed Shift TechnologyÂ
Ja
Intel Turbo Boost Technology ‡Â
2.0
Intel Hyper-Threading Technology ‡Â
Ja
Intel 64 ‡Â
Ja
Instruction SetÂ
64-bit
Instruction Set ExtensionsÂ
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle StatesÂ
Ja
Enhanced Intel SpeedStep® TechnologyÂ
Ja
Thermal Monitoring TechnologiesÂ
Ja
Intel Volume Management Device (VMD)Â
Ja
Security & Reliability
Intel Standard Manageability (ISM) ‡Â
Ja
Intel Secure KeyÂ
Ja
Intel Control-Flow Enforcement TechnologyÂ
Ja
Intel AES New InstructionsÂ
Ja
Intel OS Guard
Ja
Execute Disable Bit ‡Â
Ja
Intel Boot GuardÂ
Ja
Mode-based Execute Control (MBEC)Â
Ja
Intel Virtualization Technology (VT-x) ‡Â
Ja
Intel Virtualization Technology for Directed I/O (VT-d) ‡Â
Ja
Intel VT-x with Extended Page Tables (EPT) ‡Â
Ja
Nur eingeloggte Kunden, die dieses Produkt gekauft haben, können eine Bewertung abgeben.
| Lieferung von | france, GERMANY |
|---|---|
| Cooling system | NEIN |
| Usage Scenario | Gaming |
| PCIe VERSION | PCIe 5.0 x 16 |
| Support Memory Channels | 2 |
| Support Memory Type | DDR5 |
| Support Chipset Models | Intel B85 |
| Default TDP / TDP | 125W |
| Number OF Therads | 20 |
| Unlocked | NEIN |
| GPU-built | Ja |
| Chip Process | 10 NM |
| Package | NEIN |
| Processor Type | Intel core i5 |
| Typ | Fourteen-Core |
| Socket Type | FCLGA1200 |
| Anwendung | Desktop |
| Markenname | Intel |
| Intel Model | 14600KF |
| Herkunft | Festlandchina |
| Number of Cores | Fourteen Cores |
| Modellnummer | Intel i5-14600KF |
