- High-concerned chemical: None
- Model Number: UR230A-B
- Brand Name: unisheen
- Origin: Mainland China
- Smart home platform: Other
- Video Input: CVBS/SVideo
- Audio Input: RCA/Line in/Mic
- Video Record Format: MP4(H.264)
- Audio Codec: AAC
- Storage Device: TF Card/USB Flash Drive
- Dimension: 220x112x22mm
- Power: DC5V1A
- included in Package: Audio Cable/USB Cable/USB Adatper
- Remoted Control: Yes
- Battery Socket: F550/F750/F970
It saves the videos onto the flash USB drives (up to 512 G ) or TF cards (up to 512 G) in MP4 format .The size of each file is 4G(FAT32) or 16G (NTFS/exFAT)
|
Feature |
* CVBS/Svideo Input* HDMI 1080p Loopout* Recording in 480p/576/1080p* Support only Audio Recording* Support Snapshot in Recording* Schedule Recording* Flash USB Drive or TF Storage* Support Play Back* Remote Control |
|
Specification |
|
|
Video Input(Switchable) |
1x CVBS/Svideo |
|
Video Resolution |
720×576/720×480 NTSC/PAL |
|
Loop Out |
1xHDMI(1080p) |
|
Audio |
RCA Audio/External Line In |
|
Display Screen |
3 Inch |
|
Remote Control |
Yes |
|
Screeshot in Recording |
Yes |
|
Only Audio Recording |
Yes |
|
Playback |
Yes |
|
Alone Mode |
|
|
Record Resolution |
1080p/576p/480p |
|
Storage Device |
Flash USB Drive(up to 512G),TF(up to 512G) |
|
Storage File System |
FAT32/exFAT/NTFS |
|
Record Format |
MP4(H.264 Codec) |
|
Video Bitrate |
4/6/8MB |
|
Audio Bitrate |
128/196/320KB |
|
Size of Each File |
4G(FAT32) or 16G(NTFS/exFAT) |
|
Schedule Recording |
Support |
|
Computer Mode |
|
|
Record Resolution |
1080p/576p/480p |
|
Compatible UVC/UAC |
Yes |
|
Comatible System |
Win10/Mac OS/Linux |
|
Compatibility with 3rd application software |
OBS/Xsplit/Wirecast/FLME/QuickTime/VLC/Potplayer/Skype |
|
Attached Software |
UXplayer(separately to buy) |
|
General |
|
|
Language |
English/Japanese/Italian |
|
Dimension(W×L×H) |
158x70x25mm |
|
Package(W×L×H) |
186x145x78mm |
|
Net/Gross Weight |
0.18kg/0.6kg |
|
Temperature |
0-55(Work),-20-80(Storage) |
|
Power/Consumption |
5V DC 1.0A/3w |
|
Included in Package |
|
|
UR230A |
1pcs |
|
RCA Cable 1.2M |
1pcs |
|
3.5mm Audio Cable 1.2M |
1pcs |
|
USB Cable 0.8M |
1pcs |
|
USB Power Adapter 5V1A |
1pcs |
|
Remote Control |
1pcs |
|
Manual |
1pcs |
