- Substancja chemiczna budząca duże obawy: Nic
- EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
- Current: 10A
- Tworzywo: Plastikowy
- Orzecznictwo: CCC
- Typ przełącznika: Remote Control
- Gwarancja: 1 Year RF 433 MHz 86 2CH Wall Panel Remote Smart Home Led Light Switch
- Odległość zdalna: Up to 50m in open space
- Numer modelu: 2201M+WP08B
- Cechy: Wireless remtoe control,Multi control,Tempered glass wall panel
- Typ przedmiotu: SWITCHES
- Nazwa marki: WenQia
- Czy to inteligentne urządzenie: NIE
- Pochodzenie: Chiny kontynentalne
- Working voltage: AC 90-240 V 50-60HZ
- Quiescent current: less than 5mA
- Max current: 10A
- Receiver size: 1.89*1.65*0.9 in(48*42*23 mm)
- RF frequency: 433MHz
- Receiving sensitivity: more than 97dbm
- Working temperature: -30~+80 Celsius
- Wall Switch size: 86*86*13 mm(3.39*3.39*0.51 in)
- Wall Switch color: Czarny
- Wall Switch battery: 1pcs 27a12v battery(Not include)
- Wall Switch features: HD tempered glass panel
- Wall Switch features2: Touch sensor on off
- Support encoding: 1527 Leaning code
- Modulation Mode: ASK superheterodyne wireless reception
- Remote operating mode: Toggle/ Latched Mode
- Shell: TAK
- Application scenario: Family, Farm, Factory, Office, Supermarket
- Application2: Garage, Light, Automated curtains, Fan, Door, Gate, LED, Lamps, Motor
- Application3: Car Sunroofs Control, Mando Garaje
- Application4: Caring for the elderly, children, women, pregnant women
Luxury black tempered glass panel,can stick on the wall
Light Switch Parameter:
Size: 1.89*1.65*0.9 in(48*42*23 mm)
Working Voltage: AC 85-240 V 50-60HZ
Max current: 10A
Frequency: 433MHz
Mode: Toggle
Feature: Small size,can hide into box
Code: 1527 learning
Wall Switch Parameter:
Size: 86*86*13 mm(3.39*3.39*0.51 in)
Battery:1pcs 27a12v battery(not include)
Working Voltage: 3V
Working Method: wireless remote control
Button: 1/2/3
Feature: HD tempered glass panel
Feature2: has double side tapes and screws
Code: 1527 learning
Remote Parameter:
Size: 110*40 mm
Battery:1pcs 27a12v battery(not include)
Working Voltage: 3V
Working Method: wireless remote control
Button: 1/2/3/4/10
Feature: Has base
Code: 1527 learning
Light Switch Parameter:
Size: 1.89*1.65*0.9 in(48*42*23 mm)
Working Voltage: AC 85-240 V 50-60HZ
Max current: 10A
Frequency: 433MHz
Mode: Toggle
Feature: Small size,can hide into box
Code: 1527 learning
Wall Switch Parameter:
Size: 86*86*13 mm(3.39*3.39*0.51 in)
Battery:1pcs 27a12v battery(not include)
Working Voltage: 3V
Working Method: wireless remote control
Button: 1/2/3
Feature: HD tempered glass panel
Feature2: has double side tapes and screws
Code: 1527 learning
Remote Parameter:
Size: 110*40 mm
Battery:1pcs 27a12v battery(not include)
Working Voltage: 3V
Working Method: wireless remote control
Button: 1/2/3/4/10
Feature: Has base
Code: 1527 learning
Mini size light switch
Can hide into box
How to Connect
You need L and N line for power supply.L and N line cannot be reversed
You need L and N line for power supply.L and N line cannot be reversed
Work in rf mode:
Toggle mode:
–Press wall switch button,relay work;press same wall switch button again,relay stop
How to pair:
Press learning button 2times,press wall switch once,Toggle mode OK
How to Clean data:
Press learning button 8times,all wall switch/remote cannot control this receiver
Why do i need to clean data?
Some times the receiver on/off automatically,there maybe an interference around,so please clean data and pair with wall switch/remote again
Use in many places
AC 85-240V 10A receiver has small size,you can use it to control many different lights.But it doesnot have dimmer function
Wireless ON/OFF control
After you pair with wall switch/remote,you can control this receiver wirelessly
Multi control
You can use remote and wall switch to control one receiver together.Also,you can use a multi buttons wall switch/remote to control many receivers at the same time
About Shipping
We will pack them well and ship it out within 48 hours after you paid the order.It is fast and safe.If you need fast shipping method like DHL,UPS,FEDEX,please contact with us.
Q&A
1.What kind of battery does this wall switch use?
It uses 1pcs 27a12v battery.It is smaller than 23a12v battery.
2.Can i use my own transmitter to control this receiver?
Our receiver is 433mhz and 1527 learning code product.If the frequency and code are same,they can work well with each other. 3.The receiver cannot work,what's going on?
First,please make sure your connection is right.It needs both L and N line.
Then,you need to pair with wall switch/remote
If there is any problems about the product,we will help you to solve it. 4.I'm a buyer,can i get a wholesale price?
Of course sir.Please contact with us,we will give you the best price.
5.Can i use remote and wall switch to control same receiver?
Of course sir.One receiver can be controlled by 20pcs remotes or 10pcs wall switches
Note
1.professional electrician should operate this product. When powering on, do not touch the antenna. Install this product without opening the protective cover
2.this receiver can work well with other 433mhz 1527 code remote.U can also use remote in our store to control this receiver.
3.When the voltage of the wall switch is insufficient, please change the battery in time (the remote distance becomes closer when the wall switch battery voltage is insufficient).
4.When using wireless electronic products, care should be taken to avoid metal masks, large electronic devices, electromagnetic fields, etc., which have strong interference sources, to avoid remote control and short receiving distance or to work normally. Please contact with us if you have any questions.We will do our best to help you.Leave a 1star feedback cannot help anything.We always checked the product before shipping,so plase donot worry about the quality.Thank you.
1.What kind of battery does this wall switch use?
It uses 1pcs 27a12v battery.It is smaller than 23a12v battery.
2.Can i use my own transmitter to control this receiver?
Our receiver is 433mhz and 1527 learning code product.If the frequency and code are same,they can work well with each other. 3.The receiver cannot work,what's going on?
First,please make sure your connection is right.It needs both L and N line.
Then,you need to pair with wall switch/remote
If there is any problems about the product,we will help you to solve it. 4.I'm a buyer,can i get a wholesale price?
Of course sir.Please contact with us,we will give you the best price.
5.Can i use remote and wall switch to control same receiver?
Of course sir.One receiver can be controlled by 20pcs remotes or 10pcs wall switches
Note
1.professional electrician should operate this product. When powering on, do not touch the antenna. Install this product without opening the protective cover
2.this receiver can work well with other 433mhz 1527 code remote.U can also use remote in our store to control this receiver.
3.When the voltage of the wall switch is insufficient, please change the battery in time (the remote distance becomes closer when the wall switch battery voltage is insufficient).
4.When using wireless electronic products, care should be taken to avoid metal masks, large electronic devices, electromagnetic fields, etc., which have strong interference sources, to avoid remote control and short receiving distance or to work normally. Please contact with us if you have any questions.We will do our best to help you.Leave a 1star feedback cannot help anything.We always checked the product before shipping,so plase donot worry about the quality.Thank you.
| Kolor | 1r, 1r 1s, 1r 2s, 1T, 1t-10, 1t-29, 1t-350853, 1w, 1w-1052, 1w-350852, 2r 1s, 2r 2s, 3r 1s, 3r 2s |
|---|---|
| Substancja chemiczna budząca duże obawy | Nic |
| EU LVD Voltage | Low voltage: Below 50Vac or 75Vdc |
| Current | 10A |
| Tworzywo | Plastikowy |
| Orzecznictwo | CCC |
| Typ przełącznika | Remote Control |
| Gwarancja | 1 Year RF 433 MHz 86 2CH Wall Panel Remote Smart Home Led Light Switch |
| Odległość zdalna | Up to 50m in open space |
| Numer modelu | 2201M+WP08B |
| Cechy | Wireless remtoe control,Multi control,Tempered glass wall panel |
| Typ przedmiotu | SWITCHES |
| Nazwa marki | WenQia |
| To inteligentne urządzenie | NIE |
| Pochodzenie | Chiny kontynentalne |
| Working voltage | AC 90-240 V 50-60HZ |
| Quiescent current | less than 5mA |
| Max current | 10A |
| Receiver size | 1.89*1.65*0.9 in(48*42*23 mm) |
| RF frequency | 433MHz |
| Receiving sensitivity | more than 97dbm |
| Working temperature | -30~+80 Celsius |
| Wall Switch size | 86*86*13 mm(3.39*3.39*0.51 in) |
| Wall Switch color | Czarny |
| Wall Switch battery | 1pcs 27a12v battery(Not include) |
| Wall Switch features | HD tempered glass panel |
| Wall Switch features2 | Touch sensor on off |
| Support encoding | 1527 Leaning code |
| Modulation Mode | ASK superheterodyne wireless reception |
| Remote operating mode | Toggle/ Latched Mode |
| Shell | TAK |
| Application scenario | Family, Farm, Factory, Office, Supermarket |
| Application2 | Garage, Light, Automated curtains, Fan, Door, Gate, LED, Lamps, Motor |
| Application3 | Car Sunroofs Control, Mando Garaje |
| Application4 | Caring for the elderly, children, women, pregnant women |
